IMS NANOeasy Connection Cutter

IMS NANOeasy Connection Cutter

$110,000.00 CAD
$110,000.00 CAD
Special Offer Sold out
Shipping calculated at checkout.

NANOeasy

Cutting work in small and medium-sized house connection pipes is done quickly and reliably with the NANOeasy. Thanks to the excellent flexibility in pipe bends, the integrated colour camera and the steering wheel that can be moved on the supply hose, you can react flexibly to the various requirements when cleaning house connections.

Technical Data
    Measurements

    Cable drum: H 877 x L 495 x W 770 mm / H 34.53 x L 19.49 x W 30.31 inches.
    Nominal Diameter

    Usable in pipes from DN 70 to DN 150 (inner diameter)
    Weight

    Cable drum: approximately 38 kg / 83.78 pounds with 15 m / 49.21 feet supply hose length, approximately 45 kg / 99.21 pounds with 25 m / 82.02 feet supply hose length.
    External Diameter Mill

    42 mm / 1.65 inches
    Components

    Cutter module, cable drum and control steering wheel
    Milling Drive

    Air-powered cutting motor
    Camera

    Integrated colour camera with LED illumination

    Camera cleaning with permanent air
    Cable Length / Cable Drum

    15 m / 49.21 ft or 25 m / 82.02 ft supply hose on cable drum

    Pneumatic and electric rotary feed-through
    Control

    Manual control by steering wheel sliding on the hose
    Features / Special Features

    90° flexibility in pipe bends from DN 100

    3.5 inch monitor
    Additional Purchase Options

    Extension to DN 150

    5 m / 16.4 ft extension cable for steering wheel
